2011 Harley-Davidson XL 883L Sportster 883 review SuperLow
The SuperLow ™ is easy to clean and fun to drive. Balanced ride and responsive handling and help the machine slides into the smooth curves with confidence. The combination of the size of the wheels, radial tires and front-end geometry contribute to exceptional handling. The final ratio is adjusted to the size of the rear wheel to ensure smooth acceleration. Generous travel rear suspension, a padded seat and easy access offer exceptional comfort handlebar. A low seat height, wide power range V-Twin style and has a full set that will appeal to many riders SuperLow.
The SuperLow ™ is easy to clean and fun to drive. Balanced ride and responsive handling and help the machine slides into the smooth curves with confidence. The combination of the size of the wheels, radial tires and front-end geometry contribute to exceptional handling. The final ratio is adjusted to the size of the rear wheel to ensure smooth acceleration. Generous travel rear suspension, a padded seat and easy access offer exceptional comfort handlebar. A low seat height, wide power range V-Twin style and has a full set that will appeal to many riders SuperLow.
The new Harley-Davidson model SuperLow reintroduced the pure enjoyment of motorcycles. Balanced and responsive handling to help the rider and the machine slides through the corners with a smooth confidence. A low seat height, the V-Twin powerband and an own style complete an attractive package. The SuperLow is an open invitation to go out and ride.
Comfort is a key part of SuperLow. A new deep seat car, a bucket shape and soft filler provides good support. Shape of the seat and its 25.5-inch height allows most riders to put feet firmly on the ground when the bike is at rest. New handlebar is shaped to provide a natural position by hand. Dual coil-over rear shocks provide 2.5 inches of wheel travel smooth.
Several interdependent technologies play a role in vehicle dynamics, especially Harley-Davidson engineers tried to achieve in the SuperLow model. Changes in the size of the tires and front fork angle again at 5.7 inches SuperLow way to feel exceptional management and feedback to the rider.
"Technology and design of the tire wheel, and control the geometry of SuperLow, the team has applied the lessons learned to develop XR1200X, which also leads to significant gains in ease of handling," said Jim Hofmann, Director of Motorcycle Product Planning. "SuperLow is obviously very different from that XR1200X motion a different task, but the topic is to achieve a careful balance between steering geometry, the profile of the tires and construction and calibration of the suspension is the same, and own success. It only takes a SuperLow around do not believe it. "
The front of 18 inches in diameter and 17-inch rear wheels are shod with Michelin ® Scorcher ® 11 radial tires. Profile, sculpture and construction of these tires were developed specifically to improve handling model SuperLow. The new wheel and tire combination of reduced mass and inertia and rear, which, when combined with the construction of the tire, improving handling and reduces steering effort.
Its low-profile radial tires, single seat and the long form of the fuel tank to a new position and attractive SuperLow is wide and low. With a suggested retail price from U.S. $ 7999 in Vivid Black, SuperLow model is the most affordable Harley-Davidson 2011 online. The SuperLow is also available in Cool Blue Pearl, and Sunglo Merlot / Vivid Black & White Birch / Sedona Orange two-tone paint.
Harley-Davidson XL 883L Sportster 883 SuperLow Model Highlights
New alloy wheels, black, broke five spoke rims with machined
NEW Wheel size: 18 x 3.5 inches front, rear 17 x 4.5 inches
NEW MICHELIN ® Scorcher ™ 11 radial tires: 120/70ZR18 front, 150/60ZR17 rear
New geometry front contributes to the manipulation
NEW 68/29 (2.34:1) final drive ratio smooth acceleration
New tank 4.5 gallons for extended range
Solo seat with a deep bucket is easy to step over, seat height is 25.5 inches
New Easy Access controlled
Revised with new rear suspension travel 2.5 inches for extra comfort
Or silver powder-coated engine cover polished
o Chrome exhaust staggered shorty with dual mufflers
Or nationally painted rear fender supports
O Sport Front Fender
Visor of polished light o
Key, Harley-Davidson XL 883L Sportster 883 features SuperLow
SuperLow ™ is easy to handle and fun to drive. Balanced and management will help the driver and the car slide into the curve with smooth confidence.
The combination of the size of the wheels, radial tires and front-end geometry contribute to exceptional handling. The final ratio is adjusted to the size of the rear wheel to ensure smooth acceleration. Generous travel rear suspension, a padded seat and easy access offer exceptional comfort handlebar. A low seat height, wide power range V-Twin style and has a full set that will appeal to many riders SuperLow.
o Evolution ® V-Twin powertrain with electronic sequential fuel injection port (ESPFI)
Or rubber mounted to reduce vibration transmission
OR 5-speed manual transmission
o Double staggered exhaust
o Disc Brakes
o Controls up to mid-Mont Or handlebar-mounted electronic speedometer
o Optional Harley-Davidson Smart Security System ® hands-free security fob
2011 Harley-Davidson XL 883L Sportster 883 SuperLow - U.S. Specifications
U.S. MSRP - Vivid Black $ 7,999, $ 8,289 solid, two-tone $ 8,499
DIMENSIONS
Length of 86.1 mm (2187 mm)
Overall Width 36.6 inches (929 mm)
Height 47.6 mm (1209 mm)
Seat height:
or Laden2 25.5 inches (648 mm)
O Weight 26.8 inches (681 mm)
Ground clearance 3.8 in. (97 mm)
Rake (steering head) 31 °
Fork Angle 29.6 °
Trail 5.7 inches (145 mm)
Wheelbase of 59.3 inches (1506 mm)
Tires (Michelin ® Scorcher ™ front "11" and rear):
Front O - Scorcher ™ "11"
O panel - Scorcher ™ "11" 120/70 ZR 150/60 ZR-18-17
Fuel capacity 4.5 gal. (17.0 L) (Witness to about 1.0 Ga).
Oil Capacity (w / filter) 2.8 QTS. (2.6 L)
Bandwidth of 1.0 QTS.
Weight:
Or £ 536 delivered. (234.1 kg)
or curb
o rated gross weight 563 pounds. (255.4 kg)
or gross axle weight 1000 lbs. (453.6 kg)
Front o £ 339. (154.0 kg)
O 661 kg rear. (300.0 kg)
ENGINE
Engine3 air-cooled, Evolution ®
The valves are pushrod engine, overhead valves for hydraulic, self-adjusting lifters, two valves per cylinder
Bore x 3 x 3.812 inches (76.2 mm x 96.8 mm)
Displacement of 53.9 cubic feet. inches (883 cc)
8.9:1 compression ratio
Sequential electronic fuel injection port System3 (ESPFI)
Air Filter Paper Cartridge
System dry sump lubrication
POWERTRAIN
Main chain drive, 57/34 ratio
Final Drive Belt, 68/29 ratio
Multi-plate clutch, wet
Transmission 5-speed
U.S. Gear ratios (total):
o 1 10 407
or second 7436
Or third 5.53
o 4th 4.583
or fifth. 3.93
CHASSIS
Frame Tubular mild steel, circular sections, cast junctions
Swingarm Mild steel, rectangular tube sections, stamped junctions, MIG welded
Front Fork 39 mm Showa ®
Coil-over rear shocks, adjustable preload double
Wheels4 Black, Split 5-spoke machined rim
Front OR 18 inches x 3.5 inches (457 mm x 89 mm)
o Rear 17 inches x 4.5 inches (432 mm x 114 mm)
Brakes:
Or type brake parts dual-piston front, single-piston rear
o type rotor patented uniform expansion rotors (diameter x width):
O Front 11.5 x 0.2 inches (292 mm x 5 mm)
or rear x 0.28 inches 10.24 inches (260 mm x 7 mm)
Suspension travel:
O 4.26-inch front wheel (108 mm)
Or rear wheel 2.12 inch (54 mm)
PERFORMANCE
Torque5 engine (SAE J1349):
o North America 55 lb-ft. @ 3500 rpm (75 Nm @ 3500 RPM)
Inclination:
or Right 24.7 °
Left 24.4 ° O
Fuel Economy6
(EPA city / highway test) 45/60 mpg (5.23/3.92 L/100 km)
ELECTRIC
Battery (International Council of Evaluation) sealed lead acid, maintenance free, 12 V, 12 amp / hour, 200 cca
Load of 30 amp, permanent magnet, single phase alternator with solid-state regulator (405 W @ 3000 RPM, 405 W peak)
Starting 1.2 kW electric with solenoid shift engagement
Lighting (as per country regulation):
Lights or (quartz halogen) 55-watt low beam, high beam of 60 W
Or rear / brake lights for lamp 8W/28W
Or the flashing lights 28W self-effacement
Or the high beam, neutral, oil pressure, indicators, engine diagnostics, low fuel, battery, security system7 (optional)
WARRANTY
Warranty8 24 months (unlimited mileage)
Service first range 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter
1 vehicles described may be different from vehicles manufactured and delivered. Specifications and prices may differ from specifications and prices of vehicles manufactured and delivered. All product descriptions (including descriptions, technical data, dimensions, measurements, ratings and competitive comparisons) are based on information available at time of publication. Although such descriptions are to notify errors and changes can happen, and accuracy is not guaranteed. Harley-Davidson may make changes at any time, prices and technical data, and may change or discontinue models without notice and without obligation. Note: The configuration of the vehicle is shown, and many of the accessories described in this catalog may be sold or used in some places. Check with your dealer for complete product information and the latest information. All models have a 6-speed transmission (VRSC ™ models and Sportster ® are 5-speed) and carbon fiber belt final drive, a multi-disc clutch diaphragm spring in oil bath, and 2 years of unlimited mileage warranty.
Two measurement reflects 180 lbs (81.7 kg) operator.
3 Recommended 91 octane or higher fuel (R + M) / 2
4 Standard and optional wheels may vary from country to country and region.
5 values are nominal. Performance may vary by country and region.
6 Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal conditions in the laboratory. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary depending on the model of motorcycle in a family. Your mileage may vary depending on your personal driving habits, weather conditions, trip length, vehicle condition and design, and other conditions. Pause mileage may vary.
7 in North America security system includes immobilizer, outside North America security system includes immobilizer and siren.
8 See the owner's manual of the bike for more information.
2011 Harley-Davidson XL 883L Sportster 883 SuperLow - Specifications Canada
Canadian MSRP - Check with your local dealer for pricing.
DIMENSIONS metric units
Length 2215 mm
Seat height
Laden 1
1695 mm load
Ground clearance 100 mm
Angle Hunt
Trail 145 mm
Wheelbase 1500 mm
Fuel capacity 17 liters
Oil capacity 2.65 L
Weight
Dry weight 251 kg
Curb 260 kg
Luggage capacity
Tie
Weight
POWERTRAIN
2 engine air-cooled, Evolution ® Air-cooled, Evolution ®
Displacement 883 cc
Dimensions inch cylinder / in.76.2 mm / 96.8 mm
Par J1349
£ 3 ft torque. @ Nm @ 3750 rpm Rpm74
Sequential Electronic Fuel System 4 Port Fuel Injection (ESPFI) sequential electronic fuel injection (ESPFI)
8.9:1 compression ratio
Chain primary drive, ratio 34/57 of the chain, the ratio 34/57
Fuel Economy
City Fuel Economy 5 23.5 l/100km
Fuel Economy Hwy 5 3.92 l/100 km
Gear Ratio (overall)
First 10.407
2nd 7.436
3e 5,53
The fourth 4.583
Fifth 3.93
Sixth
WHEELS / TYRES
Wheels
Before 6 Black, Split 5-spoke machined RimBlack, Split 5-spoke machined rim
6 Wheel Option
Bake 6 Black, Split 5-spoke machined RimBlack, Split 5-spoke machined with Rim
Tire size
First Page
Again
ELECTRICAL
Tools, handlebars electronic speedometer with odometer, time of day clock, dual trip odometer, low fuel warning light, low oil pressure, engine diagnostics screen, LED lightsHandlebar mounted electronic speedometer with odometer, time of day clock, dual trip meter, low light fuel, low oil pressure, engine diagnostics screen, LED indicator
Make seven witnesses, neutral, oil pressure, turn signals, engine diagnostics, fuel, low battery, security system (optional) beam, neutral, oil pressure, turn signals, engine diagnostics, fuel, low battery, security system (optional)
FRAME
The dual-piston front brakes, pistons rearDual single piston, single-piston rear
Parking brake
Tilt angle
Exhaust System Chrome, staggered shorty exhaust with dual mufflersChrome, staggered exhaust with dual mufflers short
COLOR OPTIONS
Vivid Black
Cool Blue Pearl
Merlot Sunglo / Vivid Black
Birch White / Sedona Black OrangeVivid
Cool Blue Pearl
Merlot Sunglo / Vivid Black
Birch White / Sedona Orange
